Blackmagic Design ATEM SDI Extreme ISO Switcher

KSh 185,000.00

Blackmagic Design

Product Highlights


  • 8-Channel 3G-SDI Live Streaming Switcher
  • Supports up to 1080p60
  • RTMP Streaming via Ethernet or USB-C
  • Record Program Out and Individual Inputs
  • 11-Input, 2-Channel Audio Mixer
  • Input Frame Rate and Format Converter
  • Re-Sync on All 3G-SDI Inputs
  • HD Multiview Output with up to 16 Views
  • Local and Software Switching
  • 4 x Upstream, 2 x Downstream Keyers

The Blackmagic Design ATEM SDI Extreme ISO Switcher is an 8-input live production switcher for live streaming. It features an integrated control panel and has advanced broadcast features. In addition to live streaming using RTMP protocols, you can also output your program as if it was a webcam over USB. The switcher’s ISO label means you can individually record each of the eight input videos as an MP4, as well as the program output via one of the USB Type-C ports. The switcher automatically generates a DaVinci Resolve project file, so you can clean it up and make changes later. This versatile switcher’s eight independent 3G-SDI inputs accept all popular HD signals up to 1080p60. Each input has discrete frame rate and format converters, and it supports re-syncing for seamless switching between a variety of pro and consumer cameras, game consoles, and computer feeds.

Blackmagic Design ATEM SDI Extreme ISO Switcher: Professional Live Production in Kenya

Elevate your live broadcast capabilities with the Blackmagic Design ATEM SDI Extreme ISO Switcher, now available at Camera Stuff Kenya. This advanced switcher is specifically built for professional videographers and broadcasters who demand the stability of SDI connections. Whether you are managing a large-scale church service in Nairobi, a corporate conference in Westlands, or a high-stakes sports broadcast, this unit provides the professional-grade control required for flawless execution.

As the leading camera store in Kenya, we recognize that professional workflows require more than just consumer-grade gear. The ATEM SDI Extreme ISO offers 8 independent 3G-SDI inputs, allowing you to connect professional broadcast cameras like the Blackmagic URSA Mini or Studio Camera over long cable runs without signal degradation.


Cinema-Grade Control and Smart Switching

The Blackmagic Design ATEM SDI Extreme ISO Switcher stands out in the camera shop Nairobi market due to its incredible “ISO” recording engine. Unlike standard switchers, this model records all 8 input sources plus the program feed simultaneously. This means you can reconstruct your entire live event in post-production with a single click.

  • 8 Standards Converted SDI Inputs: Each input features its own converter, allowing you to mix and match different HD video standards (up to 1080p60) seamlessly.

  • 9-Layer ISO Recording: Capture 8 clean feeds plus the program video as H.264 MP4 files directly to USB flash disks.

  • Direct Livestreaming: Use the built-in hardware streaming engine to go live on YouTube, Facebook, and Twitch via Ethernet.

  • 4G/5G Phone Support: Tether your smartphone via USB to use mobile data as a primary or backup internet connection—perfect for location shoots across Kenya.

  • 16-Way Multiview: Monitor all 8 inputs, plus preview and program, on a single monitor via the SDI outputs.


Why Kenyan Content Creators Choose ATEM SDI Extreme ISO

For serious content creator equipment in Kenya, this switcher is a game-changer. It eliminates the need for complex external encoders and allows for high-end production values previously reserved for television studios.

Practical Use Cases for Local Professionals:

  1. Church & Gospel Broadcasts: Manage multi-camera setups for worship services, ensuring every angle—from the choir to the pulpit—is captured in crisp HD.

  2. Hybrid Corporate Events: Integrate Macbooks and Laptops in Kenya into your presentation, switching between live speakers and slide decks with professional transitions.

  3. Post-Production Efficiency: The automatic DaVinci Resolve project file generation allows you to fix “live” mistakes in the edit suite, saving hours of manual syncing.


Professional Audio and Effects

At Camera Stuff Kenya, we know that audio is just as important as video. This switcher features a built-in Fairlight audio mixer with 6 bands of parametric EQ, compressors, and limiters. With two 3.5mm stereo inputs, you can easily connect lapel microphones or a music player for professional-sounding transitions.

To ensure your setup remains stable during long broadcasts, consider pairing this switcher with our range of professional Tripods & Monopods.


Technical Benefits for the Professional:

  • Re-Sync on All Inputs: No need for external genlock; the switcher handles all timing issues.

  • USB Webcam Out: Recognized as a standard webcam by Zoom, Teams, and Skype for high-quality virtual meetings.

  • DVE with Borders: Create professional Picture-in-Picture (PiP) effects for interviews and gameplay.


Authority Resource

For in-depth training on the Fairlight audio mixer and DaVinci Resolve integration, visit the official Blackmagic Design Training Portal.


Elevate Your Broadcast Today

The Blackmagic Design ATEM SDI Extreme ISO Switcher is the ultimate tool for the modern Kenyan broadcaster. Visit our camera shop Kenya location on Mama Ngina Street or order online for delivery across Nairobi.

Buy Now – Live Streaming Archives – Cameras Stuff Kenya Visit Our Camera Shop in Nairobi CBD

Brands

Available M/E Layers
9 M/E
Effect Types
DVE, Transition, Chroma Key, Luma Key
Generators
5 x Pattern
2 x Color
Audio Mixing
2-Channel Mixing
Processing
Switching Type
IR Remote, Pushbutton, Software
Input
Number of Video Input Sources
8
Video Inputs
8 x BNC (3G-SDI)
Input Video Format
SDI (10-Bit 4:2:2 YUV)
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 56/59.94/60 fps
720p at 50/59.94/60 fps
Audio Inputs
2 x 1/8″ / 3.5 mm TRS Stereo Analog Female
Input Audio Format
Analog
Embedded Audio Input
SDI: 2-Channel (per Input)
Output
Video Output Channels
6
Video Outputs
4 x BNC (3G-SDI) (Program)
2 x USB-C
Output Video Format
SDI (10-Bit 4:2:2 YUV)
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
USB-C (10-Bit 4:2:2 YUV)
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
Audio Outputs
1 x 1/8″ / 3.5 mm TRS Analog
Output Audio Format
Analog
Embedded Audio Output
SDI: 2-Channel (per Output)
Multiview Output
Yes
Connectivity
Other I/O
1 x RJ45 Control Input/Output
HDCP Support
No
IP Video
1920 x 1080 at 23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p Encoding
Hardware
OS Compatibility
macOS 11
macOS 12 or Later
Windows 10
Windows 11
*As of July, 2022: Check with manufacturer for the most up-to-date compatibility
Processor
Not Specified by Manufacturer
Wi-Fi
No
Bluetooth
No
Power I/O
1 x Barrel (12 VDC) Input
Power Consumption
Device: 36 W
Environmental
Operating Temperature
37 to 72°F / 5 to 40°C
Storage Temperature
14 to 140°F / -10 to 60°C
Operating Humidity
0 to 90% ()
General
Dimensions
14.56 x 5.94 x 1.56″ / 36.98 x 15.09 x 3.96 cm
Weight
3.13 lb / 1.42 kg
